| MOQ: | 1pcs |
| Price: | Negotiable |
| Standard Packaging: | 1.Wooden case and vacuum package 2.As your requirements |
| Delivery Period: | 5-8 days |
| Payment Method: | T/T, Western Union, Paypal, Credit card |
| Supply Capacity: | 5000 |
In summary, the SAMSUNG SM481 Plus pick and place machine offers advanced features and capabilities for high-speed, efficient,
and precise electronic assembly. Its versatility, accuracy, and reliability make it a valuable asset for electronics manufacturers looking to optimize
their production processes.
| Model Name | SM471plus | SM481plus | SM482plus |
| Spindles | 10 Spindles ×2 Gantry | 10 Spindles ×1 Gantry | 6 Spindles ×1 Gantry |
| Placement Speed | 78,000CPH(Optimum) | 40,000CPH(Optimum) | 30,000CPH(Optimum) |
| Placement Accuracy | ±50μm@μ±3σ | ±30μm@μ±3σ | ±30μm@μ±3σ |
| Applicable Parts | 0402 ~ 14mm(H 12mm) | 0402 ~ 42mm(H15mm) | 0402 ~ 55mm(H 15mm) |
|
Applicable PCB |
Max. 510(L) x 460(W)(Standard) | Max. 460(L) x400(W)(Standard) | Max. 460(L) x400(W)(Standard) |
| Max. 610(L) x 460(W)(Option) | Max. 1500(L) x 460(W)(Option) | Max. 1200(L) x 510(W)(Option) | |
| Dimension(mm) | 1650×1690×1458 | 1650×1680×1530 | 1650×1680×1458 |
The SM482PLUS can perform high-speed placement of chips at 40,000CPH and QFPs at one per 1.1 seconds,
respectively (each at optimum speed) by applying the on-the-fly recognition technology patented by Techwin,
which enables component placement at the highest speed among all medium speed component placers.
With one-gantry structure having a high-speed piano head with 10 nozzles,
the machine can be operated with minimum manpower using one side of the machine.
Being able to produce long boards with lengths of up to 1,500mm,
the machine boasts of its applicability to the largest PCBs among SM series component placers.
Our company supplies different kinds of products. High quality and favorable price.
We're pleased to get your Inquiry and we will come back to as soon as possible.
We stick to the principle of "quality first, service first, continuous improvement and
innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. T
o perfect our service, we provide the products with good quality at the reasonable price.
SMT machines and related products:
1.SMT equipment and accessories,nozzles, feeder, feeder parts, cutter, filter, guide, tape, mortor, belt, cylinder, smt grease/lubricant, THK grease gun ,bearing,SMD parts counter,sensor etc.
2. Nozzles & feeders&their parts for fuji, for Juki, for Yamaha, for Samsung, for Siemens, for ,for Sony....etc,all of them have large stock.
3. We sell and recycle used SMT machine
